RM20.00 - RM1,105.00
Laguna Pressure Flo Quartz Sleeve / O-Rings / Screws
Price RM20.00 - RM1,105.00
Brand Laguna
Reward Points 2
Points Needed 700
Availability In Stock
  • Laguna quartz sleeve replacement part
  • High quality meterial
  • Suitable for laguna pressure flo filter

Changing the UV-C lamp and cleaning the quartz sleeve Changing the UV-C lamp: to maintain optimum performance, the UV-C lamp should be replaced every year. An ideal time is Spring, during pre-season pond maintenance. Cleaning the Quartz Sleeve: although only iltered water passes through the UVC section of the Pressure-Flo ilter, the quartz sleeve can become coated with limescale, which will diminish the performance of the UV-C lamp. It is recommended to check and clean the quartz sleeve on a regular basis. The frequency of cleaning depends on pond conditions. In order to access the UV-C lamp and the quartz sleeve, proceed as follows:

1. Switch off the UV-C lamp by disconnecting the unit plug from the main power supply.

2. Switch off the pump that supplies the Pressure-Flo Filter.

3. Disconnect all hosing from the unit by releasing the click-it couplings (push the “press” button and pull).

4. Remove the UV-C head from the ilter by unscrewing the 4 screws that fasten the UV-C head to the ilter lid. UV-C Head is equipped with anti-loss

2pcs O-Rings included.

Model available :

- Laguna Pressure-Flo 700 & 1400 (PT1500) (PT1502)

- Laguna Pressure-Flo 2100 (PT1504)

- Laguna Pressure-Flo 3200 (PT1506)

Replacement O-Rings are custom designed to fit all Pressure-Flo Filter models. Provides a tight seal that prevents water from entering the quartz sleeve. Each pack includes two

A variety of replacement screws for Laguna Pressure-Flo Filters (total of 6 screws per pack).

Head screws
Quartz sleeve flange screws

Reviews (0)
view all
0 reviews
What's in the box

1x Laguna Pressure Flo Quartz Sleeve
